VST 5000i-05 Arbor Spec
Purpose-Built for Vegetation Management & Tree-Care Professionals
The Versalift VST5000-I Arbor Spec is engineered to meet the demanding needs of the tree-cutting and vegetation management industries. With a robust, rear-mounted design and smart operator-focused features, this unit delivers maximum performance and durability in even the toughest environments.
With a working height of 16.7 metres and a horizontal outreach of 11.2 metres, the VST5000-I gives crews the reach they need to tackle high and wide spans. A two-person bucket (SWL 317kg) and hydraulic pistol grip hand controlsoffer intuitive, responsive handling.
Rated to 66kV / 33kV electrical insulation, the VST5000-I Arbor Spec is compliant with ASNZ 1418.10 – 2025, ensuring safe use around powerlines in all conditions, including storm response.
Available in 4×2 and 4×4 chassis options.
For more information on how the VST5000i-05 can support your operations, contact our team today.
Key Features:
Rear-mounted pedestal for greater rearward reach and safer operation away from the cab
Articulated/telescopic booms for superior access in tight spaces and under service wires
Open-deck tray and reinforced headboard for safer operation around falling branches
Tilting Cab Cage with ground-level hydraulic hand-pump for ease of access
Heavy-duty 3m toolbox, ideal for long-reach saws and pruning gear
Additional tool storage: under-deck toolboxes, bog mat storage, cone racks & more
Slide-on footpads & wheel chocks with custom brackets for easy stowing
100mm slide-out vice, hydraulic chainsaw sheath, rear recovery hooks (D-shackles)
Slimline amber LEDs, 27L water tank with soap dispenser, and optional bull bar, winch, and towbar
VST 5000i-05 Arbor Specs
| Working Height: | 16.7m |
| Height to bottom of bucket: | 15.1m |
| Horizontal Outreach: | 11.2m |
| Bucket Capacity: | 317kg |
| Crane Jib: | 660kg |
| Bucket Dimensions: | (Std) 0.61×1.22×1.07m |
| Basket Rotation: | -90 deg +90 deg |
| Insulation Rating: | 66kV/33kV |
| Minimum GVM: | 13,000kg |
| Style |
EWP |
|---|---|
| Size |
Heavy Duty |
| Height |
19m to 25m |
| Condition |
New |
